Product Description

• The 40 Ton C-Type Hydraulic Press is an industrial pressing machine used to apply controlled compressive force on metal or non-metal components for forming, bending, punching, straightening, and assembly operations.

• The machine has a C-shaped (single column) frame providing a three-side open working area for easy loading and unloading of the workpiece.

• It operates on Pascal’s Law where hydraulic oil pressure moves the piston (ram) to produce pressing force.

Technical Specifications

Capacity: 40 Ton (≈ 400 kN)

Frame Type: C-Frame / Single Column

Operation Mode: Manual / Semi-Automatic / Automatic

Stroke Length: 150 – 300 mm

Motor Power: 5 – 7.5 HP

Working Pressure: 19 – 22 MPa

Bed Size: Approx. 500 × 500 mm

Power Supply: 3 Phase AC

Control System: Electrical Control Panel / PLC

Body Material: Fabricated Mild Steel

Safety System: Two-hand push buttons, Emergency stop, Guards

Main Components

• Hydraulic cylinder and ram

• Hydraulic pump and electric motor

• Oil tank and filters

• Pressure gauge and control valves

• Electrical control panel

• C-type steel frame

• Bed/bolster plate

• Safety guards and limit switches

Working Operation

Electric motor drives the hydraulic pump

Pump generates oil pressure

Pressurized oil enters the cylinder

Ram moves downward and presses the workpiece

After operation, ram returns upward

Applications

Sheet metal bending and forming

Punching and piercing

Bearing and bush fitting

Riveting and crimping

Rubber and plastic molding

Straightening operations

Component assembly

Advantages

Full force available at any stroke position

Smooth and vibration-free operation

Energy efficient

Better control compared to mechanical press

Suitable for small and medium industries

Limitations

Not suitable for heavy forging operations

Less rigid than H-frame press

Limited throat depth
